Description
Liquid Filled Pressure Gauges – Lower Mount
Stainless Steel CaseCopperAlloyWetted Parts
Specifications:
Dial Size: 1-1/2”,2”, 2-1/2″or4″DialSizes (CrimpedCasing)
Accuracy: +/-3/2/3%
Scale: Dual Scale -PSI/Bar
Movement: CopperAlloy*
BourdonTube: CopperAlloy*
Window: Polycarbonate
Case: Stainless Steel case for protection in harsh environmentsConnection: CopperAlloyLowerMount*; 1/8”NPTfor1-1/2”dial, 1/4”NPTfor
2”and2-1/2”dials,and1/4″NPT,3/8″NPT,or1/2”NPTfor4”dials
1-1/2″ 2″ 2-1/2″ 4″
Range Part# Part# Part# Part#
-30HG/0
PB158L-V00
PB204L-V00
PB254L-V00
PB404/3/5L-V00
-30HG/15PSI
PB158L-V15
PB204L-V15
PB254L-V15
PB404/3/5L-V15
-30HG/30PSI
PB158L-V30
PB204L-V30
PB254L-V30
PB404/3/5L-V30
-30HG/60PSI
PB158L-V60
PB204L-V60
PB254L-V60
PB404/3/5L-V60
-30HG/160PSI
PB158L-V160
PB204L-V160
PB254L-V160
PB404/3/5L-V160
15PSI
PB158L-015
PB204L-015
PB254L-015
PB404//53L-015
30PSI
PB158L-030
PB204L-030
PB254L-030
PB404/3/5L-030
60PSI
PB158L-060
PB204L-060
PB254L-060
PB404/3/5L-060
100 PSI
PB158L-100
PB204L-100
PB254L-100
PB404/3/5L-100
160 PSI
PB158L-160
PB204L-160
PB254L-160
PB404/3/5L-160
200 PSI
PB158L-200
PB204L-200
PB254L-200
PB404/3/5L-200
300 PSI
PB158L-300
PB204L-300
PB254L-300
PB404/3/5L-300
400 PSI
PB158L-400
PB204L-400
PB254L-400
PB404/3/5L-400
500 PSI
PB158L-500
PB204L-500
PB254L-500
PB404/3/5L-500
600 PSI
PB158L-600
PB204L-600
PB254L-600
PB404/3/5L-600
1,000PSI
PB158L-K01
PB204L-K01
PB254L-K01
PB404/3/5L-K01
1,500PSI
PB158L-K015
PB204L-K015
PB254L-K015
PB404/3/5L-K015
2,000PSI
PB158L-K02
PB204L-K02
PB254L-K02
PB404/3/5L-K02
3,000PSI
PB158L-K03
PB204L-K03
PB254L-K03
PB404/3/5L-K03
4,000PSI
PB158L-K04
PB204L-K04
PB254L-K04
PB404/3/5L-K04
5,000PSI
PB158L-K05
PB204L-K05
PB254L-K05
PB404/3/5L-K05
6,000PSI
PB158L-K06
PB204L-K06
PB254L-K06
PB404/3/5L-K06
10,000PSI
PB158L-K10
PB204L-K10
PB254L-K10
PB404/3/5L-K10
15,000PSI
PB158L-K15
PB204L-K15
PB254L-K15
PB404/3/5L-K15
SIZE KEY A B C D E F G
1-1/2″ in 1.67
0.14
0.94
0.64
1/8″NPT
0.38
1.62
mm 42.4
3.46
23.8
16.3
1/8″NPT
9.5
41
2″ in 2.12
0.22
1.17
1.12
1/4″NPT
0.25
1.97
mm 54
5.6
30
28
1/4″NPT
6.4
50
2-1/2″ in 2.67
0.24
1.19
1.16
1/4″NPT
0.26
2.44
mm 68
6.1
30
29
1/4″NPT
6.5
62
4″ in 4.3
0.3
1.42
129
1/4″or3/8”NPT
0.29
3.91
mm 109
7.6
36
32.8
1/4″or3/8”NPT
7.4
99
Normal Ambient Temp:-4°Fto140°F
(-20°Cto60°C)
liquid filling: Glycerin oil filled to enhanced reliability and integrity; helps dampen the effect of vibration and pulsation; lubricates the movement and extends the life of gauge.
